The TCA pipe chain conveyor is a new type of environmentally friendly continuous conveying equipment developed for powder, granular and small block materials. Adopting fully enclosed pipeline chain transmission structure, it realizes sealed dust-free material transportation without material leakage and dust overflow. Featuring flexible 3D turning and lifting layout, it can adapt to complex workshop space and realize multi-point feeding and discharging. With stable low-speed operation, it will not damage the material structure, and is widely used in automatic conveying of plastic powder, particles, chemical raw materials, feed and building materials, matching with various mixing and batching production lines.
Technical Parameters:
| Type | Motor Power(kw) | Pipe Size | Speed(r/min) | Capacity(m3/h) |
| TCA-80 | 0.37~3 | DN80 | 6-30 | 0.3~5 |
| TCA-100 | 0.4~4 | DN100 | 6-30 | 0.45~8 |
| TCA-125 | 0.55~5.5 | DN125 | 6-25 | 3~19 |
| TCA-150 | 2~7.5 | DN150 | 8-20 | 5~27 |
