The vacuum automatic feeder adopts negative pressure vacuum adsorption principle to realize fully enclosed automatic conveying of plastic powder and particles. It completely solves the problems of dust pollution, material waste and low efficiency caused by manual feeding. With stable suction, no blockage and fast feeding speed, this vacuum feeding machine can be directly matched with mixers, extruders and granulators. Featuring intelligent automatic control, simple operation and low failure rate, it is the most cost-effective dust-free feeding equipment for small and medium plastic production lines.
Technical Parameters
| Model: | ZKF-300 | ZKF-500 | ZKF-800 | ZKF-1000 | ||
| Motor power (kw) | 2.2 | 5.5 | 7.5 | 11 | ||
| Feeding capacity (kg/h) | Distance (M) | 5 | 300 | 500 | 800 | 1000 |
| 10 | 150 | 300 | 450 | 700 | ||
| 15 | 360 | 500 | ||||
| Conveying hose ID (mm) | 31 | 51 | 63 | 63 | ||
| Suction air hose ID(mm) | 51 | 63 | 76 | 76 | ||
